We supply forged Titanium Threaded Flange (TH / Screwed Flange), CNC machined from Gr1, Gr2, Gr5, Gr7 and Gr12 titanium alloy, conforming to ASTM B381 & ASME B16.5 standards. This titanium threaded flange is designed with internal NPT or BSP thread, no welding required for pipe connection. It features easy installation & removal, excellent acid, alkali and seawater corrosion resistance. Widely used for chemical instrument piping, offshore oil & gas instrument lines, marine desalination, pharmaceutical and water treatment low-pressure systems where welding is not allowed. We support custom sizes, RF raised face and different thread types, OEM drawing service. As a professional titanium manufacturer, we offer factory wholesale, free samples and competitive price.
|
Standard |
ASME,JIS,DIN,GB,GOST |
|
Material Designation |
TA1,TA2,TA9,TA10,GR1,GR2,GR7,GR12,GR16,N5,N6,N7 etc. |
|
Size |
DN10-DN150 |
|
OEM/ODM |
Available |
|
Pressure |
PN6,PN10,PN16,PN25,PN40, |
|
Technics |
Forged |
|
Sealing Surface |
RF,FF |
|
Type |
Threaded flange |
|
Packaging |
Export standard wooden case, or can be customized |
|
Application |
Petroleum, chemical, shipbuilding, pharmaceutical, metallurgy, machinery, stamping elbow, food and other |
PN 25(mm)
|
Diameter Nominal |
Outer diameter of steel pipe |
Connection size |
Flange thickness |
Flange neck |
Flange height |
Pipe thread specification |
|||||
|
Flange outside diameter |
Diameter of center circle of bolt hole |
Bolt hole diameter |
Number of bolt holes |
bolt |
|||||||
|
N |
R |
||||||||||
|
10 |
17.2 |
90 |
60 |
14 |
4 |
M12 |
16 |
30 |
4 |
22 |
3/8 |
|
15 |
21.3 |
95 |
65 |
14 |
4 |
M12 |
16 |
35 |
4 |
22 |
1/2 |
|
20 |
26.9 |
105 |
75 |
14 |
4 |
M12 |
18 |
45 |
4 |
26 |
3/4 |
|
25 |
33.7 |
115 |
85 |
14 |
4 |
M12 |
18 |
52 |
4 |
28 |
1 |
|
32 |
42.4 |
140 |
100 |
18 |
4 |
M16 |
18 |
60 |
6 |
30 |
1-1/4 |
|
40 |
48.3 |
150 |
110 |
18 |
4 |
M16 |
18 |
70 |
6 |
32 |
1-1/2 |
|
50 |
60.3 |
165 |
125 |
18 |
4 |
M16 |
20 |
84 |
6 |
34 |
2 |
|
65 |
76.1 |
185 |
145 |
18 |
8 |
M16 |
22 |
104 |
6 |
38 |
2-1/2 |
|
80 |
88.9 |
200 |
160 |
18 |
8 |
M16 |
24 |
118 |
8 |
40 |
3 |
|
100 |
114.3 |
235 |
190 |
22 |
8 |
M20 |
24 |
145 |
8 |
44 |
4 |
|
125 |
169.7 |
270 |
220 |
26 |
8 |
M24 |
26 |
170 |
8 |
48 |
5 |
|
150 |
168.3 |
300 |
250 |
26 |
8 |
M24 |
28 |
200 |
10 |
52 |
6 |
Titanium flanges, with their high strength-to-weight ratio, high-temperature resistance, corrosion resistance and
excellent fatigue performance,have become core components in six high-end sectors: Aerospace,Petrochemicals,
Marine Engineering, New Energy, Electronics and Environmental Protection.
