Titanium tee, also known as titanium tee pipe fittings or titanium tee joints, titanium tee pipe fitting has three openings mainly used to change the direction of the fluid. Titanium tees can be used in various situations where three identical or different pipes need to be joined together. Titanium tees come in various types such as T-shaped, Y-shaped, equal-diameter pipe ends, and reduced-diameter pipe ends.
Titanium tees are processed by specific techniques such as hydraulic bulging and hot pressing to ensure they have good sealing performance and structural strength. In addition, titanium tees have excellent corrosion resistance in various media and feature low density, high strength, smooth surface and non-staining. Therefore, they are widely used in various industrial fields.
We titanium tees specifications cover DN15-DN1200, and also support non-standard customization accordingly to customer’s requirements or drawings. Our titanium tees are manufactured critically to the exact standard, including ASME,JIS,DIN,GB,GOST international standards to meet different requirements from the customers worldwide.
|
Standard |
ASME,JIS,DIN,GB,GOST,ISO |
|
Material Designation |
TA1、TA2、TA9、TA10、GR1、GR2、GR7、GR12、GR16、N5、N6、N7.etc |
|
Size |
DN15-DN1200 |
|
OEM/ODM |
Available |
|
Surface Finish |
shot blasting, sand-blasting |
|
Technics |
Weld |
|
Type |
Tees |
|
Packaging |
Export Standard Wooden case, or can be customized |
|
Application |
Electrolytic cells, reactors, distillation towers, concentrators, separators, heat exchangers, pipes, electrodes, pipes for seawater desalination, pumps, valves and pipe fittings for offshore oil drilling, etc. are used in industries such as chlor-alkali, soda ash, plastics, petrochemicals, metallurgy and salt production |
(mm)
|
Nominal size |
Outside diameter at bevel d |
45° Elbow |
||
|
I series |
ⅡSeries |
Tube pass C |
Exit M |
|
|
15 |
21.3 |
18 |
25 |
25 |
|
20 |
26.7 |
25 |
29 |
29 |
|
25 |
33.4 |
32 |
38 |
38 |
|
32 |
42.2 |
38 |
48 |
48 |
|
40 |
48.3 |
45 |
57 |
57 |
|
50 |
60.3 |
57 |
64 |
64 |
|
65 |
73.0 |
76 |
76 |
76 |
|
80 |
88.9 |
89 |
86 |
86 |
|
90 |
101.6 |
————— |
95 |
95 |
|
100 |
114.3 |
108 |
105 |
105 |
|
125 |
141.3 |
133 |
124 |
124 |
|
150 |
168.3 |
159 |
143 |
143 |
|
200 |
219.1 |
219 |
178 |
178 |
|
250 |
273.0 |
273 |
216 |
216 |
|
300 |
323.8 |
325 |
254 |
254 |
|
350 |
355.6 |
377 |
279 |
279 |
|
400 |
406. 4 |
426 |
305 |
305 |
|
450 |
457 |
480 |
343 |
343 |
|
500 |
508 |
530 |
381 |
381 |
|
550 |
559 |
———— |
419 |
419 |
|
600 |
610 |
630 |
432 |
432 |
|
… |
… |
… |
… |
… |
|
1 200 |
1 219 |
1 220 |
889 |
838 |
|
Suitable for the cross below DN600. Tees and cross above DN650, recommend exit size. |
||||
