We supply high-quality Titanium 45° buttweld elbow and titanium 45 degree pipe bend, available in Gr1, Gr2, Gr5, Gr7, Gr12, compliant with ASTM B363, ANSI B16.9. We provide seamless & welded types, long radius (1.5D LR) and short radius (1D SR), various wall thickness SCH10S, SCH40S, STD, XS. Surface options: raw, pickled, sandblasted, polished, mirror polished. Featured with excellent corrosion resistance against seawater, chloride, acid & alkali, non-magnetic, high specific strength, lightweight. Widely used in chemical processing, marine offshore, desalination, heat exchanger, sanitary pharma, exhaust, oil & gas pipeline systems. Custom drawing & dimension service supported.
|
Standard |
ANSI,ASME,DIN,JIS,GB/T |
|
Material Designation |
TA1/TA2/TA9/TA10/GR1/GR2/GR7/GR12/N5/N6 etc |
|
Size |
DN15-DN1200 |
|
OEM/ODM |
Available |
|
Titanium Surface Finish |
Shot blasting, Sand blasting |
|
Technics |
Welding, Seamless |
|
Type |
Titanium 45 Degree Elbow |
|
Packaging |
Export Standard Wooden case, or can be customized |
|
Application |
Chemistry, petrochemicals and general industries: electrolytic cells, reactors, distillation towers, concentrators, separators, heat exchangers, pipelines, electrodes, etc. in chlor-alkali, soda ash, plastics, petrochemicals, metallurgy, salt production and other industries. Marine engineering: pipelines for seawater desalination, pumps, valves, pipe fittings for offshore oil drilling, etc |
（mm）
|
Nominal size |
Outside diameter at bevel |
Center to end |
|||
|
45° elbow |
90° elbow |
||||
|
I Series |
II Series |
Major radius |
Major radius |
Short radius |
|
|
15 |
21.3 |
18 |
16 |
38 |
——— |
|
20 |
26.7 |
25 |
19 |
38 |
——— |
|
25 |
33.4 |
32 |
22 |
38 |
25 |
|
32 |
42.2 |
38 |
25 |
48 |
32 |
|
40 |
48.3 |
45 |
29 |
57 |
38 |
|
50 |
60.3 |
57 |
35 |
76 |
51 |
|
65 |
73.0 |
76 |
44 |
95 |
64 |
|
80 |
88.9 |
89 |
51 |
114 |
76 |
|
90 |
101.6 |
57 |
133 |
89 |
|
|
100 |
114.3 |
108 |
64 |
152 |
102 |
|
125 |
141.3 |
133 |
79 |
190 |
127 |
|
150 |
168.3 |
159 |
95 |
229 |
152 |
|
200 |
219.1 |
219 |
127 |
305 |
203 |
|
250 |
273.0 |
273 |
159 |
381 |
254 |
|
300 |
323.8 |
325 |
190 |
457 |
305 |
|
350 |
355.6 |
377 |
222 |
533 |
356 |
|
400 |
406.4 |
426 |
254 |
610 |
406 |
|
450 |
457 |
480 |
286 |
686 |
457 |
|
500 |
508 |
530 |
318 |
762 |
508 |
|
550 |
559 |
——— |
343 |
838 |
559 |
|
600 |
610 |
630 |
381 |
914 |
610 |
|
650 |
660 |
——— |
406 |
991 |
——— |
|
700 |
711 |
720 |
438 |
1 067 |
——— |
|
750 |
762 |
——— |
470 |
1 143 |
——— |
|
800 |
813 |
820 |
502 |
1 219 |
——— |
|
850 |
864 |
——— |
533 |
1 295 |
——— |
|
900 |
914 |
920 |
565 |
1 372 |
——— |
|
950 |
965 |
——— |
600 |
1 448 |
——— |
|
1 000 |
1 016 |
1 020 |
632 |
1 524 |
——— |
|
1 050 |
1 067 |
——— |
660 |
1 600 |
——— |
|
1 100 |
1 118 |
1 120 |
695 |
1 676 |
——— |
|
1 150 |
1 168 |
——— |
727 |
1 753 |
——— |
|
1 200 |
1 219 |
1 220 |
759 |
1 829 |
——— |
Titanium pipe fittings are tubular connecting parts mainly made of titanium and titanium alloys. Titanium metal
